The Next Generation of Inverted Coasters

The Infinity Inverted Coaster offers endless roller coaster possibilities and provides unlimited fun with the special effect of having no track underneath you. Proven and innovative technologies offer maximum ride comfort and smoothness, while passengers experience the most exciting ride elements.

The two-seater vehicles feature a large seat distance and plenty of free space to all sides to experience the sensation of gliding freely. In combination with the layout, the trains allow unlimited possibilities: airtime, inversions, inclined lifts, vertical lifts, LSM launches, shuttle layouts and much more.

Thanks to its individual configuration options, the Infinity Inverted Coaster is flexibly customized to your requirements and leaves nothing to be desired.

More Information


The trains of the Infinity Inverted Coaster are designed with optimal use of non-welded and welded assemblies to achieve lightweight construction and ease of maintenance. With a large running wheel diameter as well as suspended running, side and upstop wheels, they master high speeds smoothly.

Thanks to their agility, the trains easily maneuver through small vertical or horizontal radii. Their ability to accommodate high accelerations enables the creation of exciting layouts even on a small footprint. The train length can be individually adapted to your capacity requirements from 4 to 12 rows of seats for 2 persons each.

The tripartide Infinity seating concept offers passengers secure hold and plenty of freedom at the same time as well as maximized comfort. Continuously adjustable lap bars adapt individually to each passenger and offer the greatest possible safety thanks to redundant locking and optional belt system.


By means of a chain lift with any desired inclination of up to 90°, the train of the Infinity Inverted Coaster climbs to dizzying heights. Likewise, it can also be launched into the layout with a single or pendulum launch using linear synchronous motors. Of course, the use of multiple launch sections and therefore the upgrade to a true inverted multi-launcher is possible. The flexibly adaptable concept even allows lifts and launches to be combined in one layout.

With the ability to run forwards and backwards, the Infinity Inverted Coaster offers options for closed layouts with pendulum launches or shuttle layouts where the train travels the same track forwards and in the opposite direction backward. The use of switches for separate ride sections allows for an even more varied ride experience.

Technical Details

To ensure safe operation and efficient maintenance, the Infinity Inverted Coaster comes with many features that allow an easy handling of the attraction, such as:

  • State-of-the-Art safety PLC
  • Operator panel incl. color touch display
  • Suspended running wheels with large diameter
  • Easily adjustable side and upstop wheels with adjustable suspension
  • Wear-free magnetic eddy current brakes
  • Contact-free acceleration by linear synchronous motors
  • Silent anti-rollback dog with automatic function monitoring at each round

Theming Options

Whether as an impressive stand-alone attraction or as part of an extensively designed themed world: The individual theming options of the Infinity Inverted Coaster create the highest recognition value and perfectly convey the design of a themed area.

In addition to the customizable appearance, the vehicles can be equipped with on-board sound as well as lights, providing not only a high-thrill, but also a high-tech immersive experience.

Layout Examples

Launched Infinity Inverted Coaster 350

37m / 121 ft
95 km/h / 59 mph
350 m / 1148 ft
Track Length
Experienced Track Length560 m / 1837 ft
Width112 m / 368 ft
Depth60 m / 197 ft
Track Width900 mm
Vertical Acceleration minimal-1.0 g
Vertical Acceleration maximal4.7 g
Trains (16 personen)1
Capacity550 pph
Connected Load
with energy storage
2200 kW
350 kW


Infinity Inverted Coaster 355

26 m / 85 ft
72 km/h / 45 mph
355 m / 1165 ft
Track Length
Width145 m / 476 ft
Depth31 m / 102 ft
Track Width900 mm
Vertical Acceleration minimal-0.3 g
Vertical Acceleration maximal3.5 g
Trains (12 persons)2
Capacity750 pph
Connected Load210 kW



We design individual and customized layouts upon request.

All figures are approximate. Design and specifications are subject to change.
